Schematics, Boards Overlays, and Parts Lists: Keypad Board (84012282001) 8-393
D11 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D13 NOTPLACED –
D14 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D16 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2521M4 4871785H01 SWITCHING DIODE
BAS116LT1G
E2001 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2002 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2003 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
FL1 9171981H01 FILTER 6 CHANNEL EMI
ESD 12PIN
FL2 9171981H01 FILTER 6 CHANNEL EMI
ESD 12PIN
J2002 09012073001 CONNECTOR, B2B
RECEPTACLE 34PINS
M2533M4 3987977Y01 CONTACT ANTENNA UNI-
VERSAL (D35)
P1000 0970312N01 CONN,BTB,RCPT,60CONT
,.4MM,GLD,1 STACK HGT
P2000 0970312N01 CONN,BTB,RCPT,60CONT
,.4MM,GLD,1 STACK HGT
P2001 0970312N01 CONN,BTB,RCPT,60CONT
,.4MM,GLD,1 STACK HGT
PCB 84012282001 BOARD, PC , KEYPAD
Q2537M4 4888795V06 XSTR,FET GP
PWR,,,MOS-
FET,,SM,,,SMT,20V,.25W,L
EAD-FREE
Q2547M4 4888795V06 XSTR,FET GP
PWR,,,MOS-
FET,,SM,,,SMT,20V,.25W,L
EAD-FREE
R1 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2 0613952R17 CER CHIP RES 47K OHM
5% 0402
Ref. Des. Part Number Description
R3 0613952R17 CER CHIP RES 47K OHM
5% 0402
R4 0613952R17 CER CHIP RES 47K OHM
5% 0402
R5 0613952R17 CER CHIP RES 47K OHM
5% 0402
R6 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R7 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R8 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R9 NOTPLACED –
R10 NOTPLACED –
R11 NOTPLACED –
R12 NOTPLACED –
R13 NOTPLACED –
R14 NOTPLACED –
R15 NOTPLACED –
R16 0613952Q67 CER CHIP RES 560 OHM
5 0402
R17 NOTPLACED
R19 0613952Q67 CER CHIP RES 560 OHM
5 0402
R2003 0613952Q53 CER CHIP RES 150 OHM
5 0402
R2004 0613952Q49 CER CHIP RES 100 OHM
5 0402
R2005 0613952Q66 CER CHIP RES 510 OHM
5 0402
R2006 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2007 0613952Q49 CER CHIP RES 100 OHM
5 0402
R2013 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2014 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
Ref. Des. Part Number Description
R2024 0613952Q09 CER CHIP RES 2.2 OHM 5
0402
R2025 0613952Q09 CER CHIP RES 2.2 OHM 5
0402
R2500 NOTPLACED –
R2502 NOTPLACED –
R2531 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2533 NOTPLACED –
R2404M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2405M3 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2406M3 NOTPLACED –
R2407M3 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2408M3 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2412M3 0613952Q53 CER CHIP RES 150 OHM
5 0402
R2414M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2416M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2418M3 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2419M3 0613952Q49 CER CHIP RES 100 OHM
5 0402
R2433M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2434M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2435M3 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2436M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2437M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2441M3 0613952Q41 CER CHIP RES 47.0 OHM
5 0402
Ref. Des. Part Number Description
R2442M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2443M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2444M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2449M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2450M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2451M3 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2452M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2453M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2454M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2455M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2456M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2457M3 0613952R05 CER CHIP RES 15K OHM
5% 0402
R2458M3 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2459M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2460M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2461M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2465M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2466M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2467M3 0613952Q32 CER CHIP RES 20.0 OHM
5 0402
R2469M3 NOTPLACED –
R2470M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
Ref. Des. Part Number Description
