8-394 Schematics, Boards Overlays, and Parts Lists: Keypad Board (84012282001)
R2471M3 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2472M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2473M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2474M3 0613952R35 CER CHIP RES 270K OHM
5% 0402
R2475M3 0613952Q53 CER CHIP RES 150 OHM
5 0402
R2476M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2477M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2478M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2479M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2480M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2481M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2484M3 0613952Q35 CER CHIP RES 27.0 OHM
5 0402
R2485M3 0613952Q35 CER CHIP RES 27.0 OHM
5 0402
R2486M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2487M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2488M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2489M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2490M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2491M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2492M3 0613952R01 CER CHIP RES 10K OHM
5% 0402
Ref. Des. Part Number Description
R2493M3 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2495M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2496M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2497M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2498M3 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2501M4 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2503M4 NOTPLACED –
R2505M4 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R2507M4 0613952R49 CER CHIP RES 1.0M OHM
5% 0402
R2508M4 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2509M4 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2511M4 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2512M4 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2513M4 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R2514M4 NOTPLACED –
R2515M4 NOTPLACED –
R2516M4 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
R2517M4 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2519M4 0613952H25 CER CHIP RES 10.0 OHM
5% 0603
R2522M4 0613952R74 RES,MF,10MOHM,5%,.062
5W,SM,0402,400PPM/
CEL,PB-FREE
R2523M4 0613952R74 RES,MF,10MOHM,5%,.062
5W,SM,0402,400PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R2524M4 0613952R49 CER CHIP RES 1.0M OHM
5% 0402
R2529M4 0613952P30 CER CHIP RES 200K OHM
1 0402
R2530M4 0613952P30 CER CHIP RES 200K OHM
1 0402
R2560M4 0613952R66 CER CHIP RES 0.0 +/-
0.050 OHM
SH1 26012170001 SHIELD, MACE
SH2 26012171001 SHIELD, SDRAM
U2402M3 51002923001 IC,LNR V REGLTR,3.3V
LP2989,NOPB
U2403M3 51009735001 IC, RCVR, ONE-CHAN,
QFN, LF WAKE-UP
U2406M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2407M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2408M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2409M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2410M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2411M3 5175856M01 DUAL INVERTER
U2412M3 5114007M45 IC,NOR,1PER PKG,SOT-
353,PB-FREE
U2413M3 51010274001 IC,SDRAM,128MBIT,8MX1
6,7.5NS, SCRND
U2414M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2415M3 51009372001 IC MICROCONTROLLER
AT32UC3A0512
U2416M3 51009669001 IC, ACCELEROMETER,
MOTION SENSOR
U2417M3 5102836C11 IC,ANLG
SW,,FSA4157,SM,,,,SPDT,,
PB FREE
U2473M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
Ref. Des. Part Number Description
U2478M3 5164852H16 IC TRANSCEIVER W/
LEVEL TRANSLATION
U2510M4 5185912Y05 IC,MICROPROCES-
SOR,INDIGENOUS MACE
U2525M4 5171339H01 MICROPOWER VOLTAGE
REGULATOR
U2526M4 5171988H01 CMOS COMPARATOR
VR1 NOTPLACED –
Y2475M3 48009319001 SMD CRYSTAL OSCILLA-
TOR DS0211AR
