xii ASTRO APX 1000 UHF1 Model Chart
ASTRO APX 1000 UHF1 Model Chart
MODEL DESCRIPTION: UHF1, APX 1000
FCC ID: AZ489FT4917
H84QDD9PW5AN Model 1.5 APX 1000, 380–470MHz, 1–5 Watts, Standard Control
H84QDF9PW6AN Model 2 APX 1000, 380–470MHz, 1–5 Watts, Limited Keypad
H84QDH9PW7AN Model 3 APX 1000, 380–470MHz, 1–5 Watts, Full Keypad
ITEM NUMBER DESCRIPTION
X PMLN6654_ Assembly, Front Kit, Model 1.5, APX 1000
X PMLN6805_ Assembly, Front Kit, Model 2, APX 1000
X PMLN6645_ Assembly, Front Kit, Model 3, APX 1000
XXX 0378212A02 Screw, Retainer, Keypad
XXX 42012056001 Retainer, Keypad
X 75012207001 Keypad, Model 1.5
X 75012114003 Keypad, Model 2
X 75012114001 Keypad, Model 3 (English)
X 75012114002 Keypad, Model 3 (Chinese)
X 75012114004 Keypad, Model 3 (Cyrillic)
X 75012114005 Keypad, Model 3 (Arabic)
X 75012114006 Keypad, Model 3 (Hebrew)
XXX 0104059J56 Assembly, Flex, Keypad
X PMCN4036A Assembly, Keypad Board, Model 1.5, Base, APX 1000
X PMCN4040A Assembly, Keypad Board, Model 2, Base, APX 1000
X PMCN4037A Assembly, Keypad Board, Model 3, Base, APX 1000
X 40012085001 Mylar with Metal Domes, Model 1.5 Keypad
X 40012056002 Mylar with Metal Domes, Model 2 Keypad
X 40012056001 Mylar with Metal Domes, Model 3 Keypad
XXX 75012224001 Conductive Pad, Keypad Retainer
XXX 0104059J61 Assembly, Flex, Back Mic
XXX 35012068001 Membrane, Back Mic
XXX 32012282001 Boot, Back Mic
XXX 64012022001 Backer, Back Mic
XXX 27012020002 Chassis
XXX 32012150001 Seal, Battery Contact
XXX 15012140001 Shroud
XXX 32012156001 O-ring, Main
XXX PMLN6797_ Main Board, APX 1000 (UHF1)*
XXX 7515719H02 Pad, Thermal, RF PA
XXX 43012045001 Collar, Plastic
XXX 6071520M01 Coin Cell
XXX HW000071A01 EMI Absorber
XXX 0386104Z10 Screw, Chassis (APX 1000)
XXX 3286058L01 Seal, Vacuum Port
XXX 5478220A01 Label, Ventilation
●● 54012196002 Label, Front_NamePlate (APX 1000)
●● 54012198004 Label, Back (APX 1000)
XXX 54012241001 Label, Bottom
XXX 36012020002 Knob, Multi Function
XXX 15012142001 Cover, Accessory-Connector
XXX PMLN7029_ User Guide CD, APX 1000
Note:
X = Item Included.
= Option available. Can be serviced in depot and ordered thru AAD.
Refer
Appendix A for antennas, batteries and other applicable accessories.
* The radio’s model number and FLASHcode are required when placing an order for the Main Board.
The model number and (sometimes) the FLASHcode can be found on the FCC label on the back of the radio.
The model number and the FLASHcode can be found by putting a Model 1.5, 2 or 3 radio into the Test Mode.
The model number and FLASHcode can be found by using the Programming Cable (PMKN4012B or PMKN4013C)
and the CPS to read a Model 1.5, 2 or 3 radio.
