ASTRO APX 1000 900 MHz Model Chart xi
ASTRO APX 1000 900 MHz Model Chart
MODEL DESCRIPTION:
BT Models FCC ID:
900 MHz, APX 1000
AZ489FT5864
H84WCF9PW6AN Model 2 APX1000, 896–941MHz, 1.0–3.9 Watts, Limited Keypad
ITEM NUMBER DESCRIPTION
X PMLN5907_ Assembly, Front Kit, Model 2
X 0378212A02 Screw, Retainer, Keypad
X 42012056001 Retainer, Keypad
X 75012114003 Keypad, Model 2
X PMLN6210_ Assembly, Keypad Board, Model 2, Base
X 40012056002 Mylar with Metal Domes, Model 2 Keypad
X 0104059J61 Assembly, Flex, Back Mic
X 35012068001 Membrane, Back Mic
X 32012282001 Boot, Back Mic
X 64012022001 Backer, Back Mic
X 27012020002 Chassis
X 32012150001 Seal, Battery Contact
X 15012140001 Shroud
X 32012156001 O-ring, Main
X PMLN7028_ Assembly, Main Board (900 MHz)*
X 7515719H02 Pad, Thermal, RF PA
X 43012045001 Collar, Plastic
X 6071520M01 Coin Cell
X 0104043J76 Assembly, Flex, Back-kit (Model 2)
X 0104046J48 Assembly, Shield, Secondary
X 0386104Z04 Screw, Chassis
X 3286058L01 Seal, Vacuum Port
X 5478220A01 Label, Ventilation
● 54012196002 Label, Front_NamePlate (Non-Bluetooth – Basic)
● 54012198004 Label, Back (APX 1000)
X 54012241001 Label, Bottom
● 54012255001 Label, Front, Color Talk Group
X 36012020002 Knob, Multi Function
X 15012142001 Cover, Accessory-Connector
X PMLN7029_ User Guide CD, APX 1000
Note:
X = Item Included.
● = Option available. Can be serviced in depot and ordered thru AAD.
• Refer
Appendix A for antennas, batteries and other applicable accessories.
* The radio’s model number and FLASHcode are required when placing an order for the Main Board.
• The model number and (sometimes) the FLASHcode can be found on the FCC label on the back of the radio.
• The model number and the FLASHcode can be found by putting a Model 2 or 3 radio into the Test Mode.
• The model number and FLASHcode can be found by using the Programming Cable (PMKN4012B or PMKN4013C) and the
CPS to read a Model II, or III radio.
