Exploded Views and Parts Lists: APX 1000 Back Kit Exploded View Parts List 9-5
9.4 APX 1000 Back Kit Exploded View Parts List
NOTE:
†
. Items cannot be ordered individually. They are included in their respective kits (if ordered). Refer to the Model
Charts on page xi.
††
. Item is not orderable.
Item
No.
Motorola Part
Number
Description
29 0386104Z04 Screw, Chassis
30 0104043J76 Assembly, Flex, Back-kit (Model 2 )
31 0104046J48 Shield, Secondary Assembly
32
†
PMLF4097_ Assembly, Main Board (900 MHz)
33 6071520M01 Cell, Coin
34 7515719H02 Pad, Thermal, RF PA
35 32012156001 O-ring, Main
36 43012045001 Collar, Plastic
37 0104059J61 Assembly, Flex, Back Mic
38 32012282001 Boot, Back Mic
39 35012068001 Membrane, Back Mic
40 27012020002 Chassis
41 32012150001 Seal, Battery Contact
42 3286058L01 Seal, Vacuum Port
43 5478220A01 Label, Ventilation
44
††
54012242001 Label, FCC
45
††
33012034001 Label, ITID
46 15012140001 Shroud
47 NNTN8129_
NNTN8128_
PMNN4424_
Battery, Hi-Cap (FM, 2300 mAH)
Battery, Standard (non-FM, 1900 mAH)
Battery, Hi-Cap (non-FM, 2300 mAH)
48 PMLN4651_
PMLN7008_
Clip, Belt (2”)
Clip, Belt (2.5”)
49 64012022001 Back Microphone Backer
