Disassembly/Reassembly Procedures: Required Tools and Supplies 8-3
8.2 Required Tools and Supplies
8.3 Fastener Torque Chart
Table 8-3 lists the various fasteners by part number and description, followed by the torque values
and the location where used. Torque all fasteners to the recommended value when assembling the
radio.
Table 8-2. Required Tools and Supplies
Tools
Motorola
Part Number
Supplier
Supplier
Part Number
Remarks
Chassis Opener 66012028001 Motorola – To remove chassis from housing.
Bit, Torx T6 – – – For speaker retainer, back kit (chassis) and
keypad retainer.
Driver, Torque – – – –
Black stick – Hexacon
Electric Co.
MA-800G For keypad rubber mushroom rib assembly
and disassembly.
Round stick – Brusia BE-MO-14383 For microphone membrane assembly.
Allen wrench – – – To loosen accessory-connector cover thumb
screw (if thumb screw is too tight).
Anti-static ground
kit
– – – To place radio and components during
disassembly and reassembly.
Vacuum Pump kit NLN9839 Motorola – For vacuum test. Requires 66012030001
Vacuum Test Fixture.
Vacuum Test
Fixture
66012030001 Brusia BE-MO-14512 To connect the vacuum/pressure hose of the
Vacuum Pump Kit to the radio.
Vacuum Cup 66012040001 Brusia PISCO
VPC10RSE4B
To enhance sealing when the vacuum test
fixture is connected to the radio.
Table 8-3. Required Tools and Supplies
Motorola
Part Number
Description Repair Torque (in-lbs)
0386104Z04 Speaker retainer and Chassis screw 3.0
0378212A02 Keypad Retainer screw 1.2
02012016001 Rotary Switch Spanner nut 4.5
