Indication Status
Blinking green Radio is receiving an individual or telephone call or is on a Priority-Two
channel while in the Scan List Programming mode.
Rapid blinking green Radio is on a Priority-One channel while in the Scan List Programming
mode.
4.3
Status Icons
The 130 x 130 pixel front liquid crystal display (LCD) of your radio shows radio status, text entries, and
menu entries. The top two display rows contain color icons that indicate radio operating conditions.
Selected icons are also shown on the first row of the 112 x 32 pixel top monochrome display screen of
your radio.
The following icons are for the front display screen unless indicated otherwise.
Top Display:
Receiving
Radio is receiving a call or data.
Top Display:
Transmitting
Radio is transmitting a call or data.
Call Received
Radio has received an Individual Call.
Top Display:
Battery
For IMPRES battery operation only – the icon shown indicates the charge
remaining in the battery.
For all battery operation – the icon blinks when the battery is low or wrong
battery is detected.
Top Display:
Received Signal Strength Indicator (RSSI)
The number of bars displayed represents the received signal strength for
the current site (trunking only) The more stripes in the icon, the stronger
the signal.
Top Display:
Roaming
The radio has roamed to and is currently registered to a foreign system.
Top Display:
Direct
On
Radio is configured for direct radio-to-radio communication (during con-
ventional operation only).
MN004476A01-AE
Chapter 4: Status Indicators
32
