15
BATTERY AND CHARGER
FEATURES
Note: If the radio is ON while charging, it will take longer
to fully charge.
5. Insert the radio (with battery installed) into the
charging pocket.
Note: The radio will fit in the charger with the holster
attached when placed face down in the tray. The
battery can be charged by itself using the slot on
the flat surface of the charging pocket.
Charging Status LEDs
On the drop-in charger, the radio charging pocket
has an LED Charger.
On the MUC, each of the 6 charging pockets has
an LED. The LEDs are grouped into pairs to show
which charging pockets are paired. The LED is red
when the battery is charging. It turns to green
once the battery is fully charged.
Note: This Multi Unit Charger allows you to clone up to 2
radios (2 Source radios and 2 Target radios). For
more details, refer to “Radio Cloning” Section on
page 21.
• For part number details, refer to the“Accessories”
Section on page 41.
Charger LED Indicator
Status LED Status Comments
Charging Steady
Red
Indication
The charger is
currently charging.
Charge
Complete
Steady
Green
Indication
Battery is fully
charged.
Battery
Fault (*)
Blinking
Red
Battery was faulty
when inserted.
Note: The LED is red when the battery is charging. It turns
to green once the battery is fully charged.
Note: (*) Re-seating the battery pack will likely correct this
issue.
