4 DIAGNOSTICS
47
AUDIO SPDIF Indicates S/PDIF Mode as set by application software.
OSD Display Description
N/A Audio S/PDIF mode is not applicable
IEC958PCM PCM audio selected
Dolby For Dolby Selection, the following speaker selection is set:
1/0 right front or left front
2/0 right front and left front
3/0 right front and left front and center
2/1 right front and left front and (right rear or left rear)
3/1 right front and left front and center and (right rear or left rear)
2/2 right front and left front and right rear and left rear
3/2 right front and left front and center and right rear and left rear
LFE: Low Frequency Effect The LFE indicates if the nomenclature low frequency effects are
available in the Dolby audio stream as indicated if the ‘0.1’ is present in
the Dolby 5.1 nomenclature (for example, ‘Dolby 5.1 surround’). Valid
values include:
OSD Display Description
0 LFE is not available
1 LFE is available (for example, ‘Dolby 5.1 surround’).
Muting State and Method The Audio and Video Mute Status indicates if the audio and/or video has
been muted by the software. The audio mute is either ‘On’ or ‘Off’. The
Video Mute describes the MPEG muting method selected by the
software and indicates if the output video is in the mute state by
displaying ‘On’ or ‘Off,’ followed by the mute method. Methods include:
OSD Display Description
UNMUTED Displayed if mute method is not selected
MUTE to STILL Displayed if the mute method includes stopping video and presenting a
still frame, similar to a pause function
MUTE to BLACK Displayed if mute method presents a black screen.
Captions The captions mode displays captions present on the service. Note: The
caption options are set via the User Setting Menu, where the subscriber
can enable closed captions and select options.
1
st
Caption Row: Caption Detected:
OSD Display Description
708 EIA-708 captions detected
608 EIA-608 captions detected
608 and 708 Both EIA-608 and EIA-708 captions detected
None No Captions detected
2
nd
Caption Row: Caption Options Set, followed by Service Selected (xxxxxxxxxxxx):
OSD Display Description
708 Set EIA-708 captions enabled, with options set by user
