Motorola DCH6416 Installation Manual

4 DIAGNOSTICS
48
xxxxxxxxxxxx
708 Default
xxxxxxxxxxxx
EIA-708 captions enabled, with no options set by user
608 Set
xxxxxxxxxxxx
EIA-608 captions enabled, with options set by user
608 Default
xxxxxxxxxxxx
EIA-608 captions enabled, with no options set by user
None Set Captions detected but not enabled
The OSD status, 2
nd
caption row displays captions based on the setting selected in the User Settings
menu and what is available in the stream.
708 or 608 is the type of caption displayed, dependent on what was detected.
The Set or Default directly reflects the User Setting Status parameter of 'SETTINGS', which is 'Auto' for
Default or 'User' for set by user via the User Setting Menu.
The xxxxxxx parameter should directly reflect the User Setting Status parameter of 'SERVICE
SELECTION' for Analog or Digital services as described below.
xxxxxxxxxxxx is the Service Selected parameter (which should directly reflect the User Setting Status
parameter of 'SERVICE SELECTION' for Analog or Digital services) and will be shown as one of the
following if captions are enabled (See section 16.5 and 16.6 for further information on service selection):
xxxxxxxxxxxx
OSD Display
Definition
CC 1 Closed Caption service CC 1 (default)
CC 2 Closed Caption service CC 2
CC 3 Closed Caption service CC 3
CC 4 Closed Caption service CC 4
T 1 Closed Caption service T 1
T 2 Closed Caption service T 2
T 3 Closed Caption service T 3
T 4 Closed Caption service T 4
Primary Lang Primary language established by the provider (default, Service 1)
Second Lang Secondary language established by the provider (Service 2)
Service 3 Set by the provider Service 3.
Service 4 Set by the provider Service 4.
Service 5 Set by the provider Service 5.
Service 6 Set by the provider Service 6.
Digital Subtitle
Status
The subtitle parameter indicates if subtitles are enabled and, if enabled, what
language is selected and if the subtitle is being rendered. The language is displayed
as the 3-character ISO639.2/B language code.
• Enabled is indicated with Yes or No.
• The language is displayed as the 3-character ISO639.2 language code.
• Enhanced mode is indicated with Yes or No.
• Rendered status is indicated with Yes or No.
