Motorola Mag One Series User Manual

Mechanical View and Parts List
Reference
No
2-13
Table 2-1 Parts List
Part No Part Name Qty
6 PMDN4007_R PTT Rubber 1
7 PMDN4010_R PTT Bezel 1
8 PMDN4011_R Speaker & Cable (non-EPP) 1
PMDN4067_R Speaker & Cable (EPP) 1
9 PMDN4012_R Speaker Bracket 1
10 Speaker Bracket Screw 1
11 PMDN4013_R Speaker Poron Pad 1
12 PMDN4046_R Speaker Felt 1
13 PMDN4014_R Volume Knob 1
14 Volume Knob D-Clip (D: 6.0) 1
15 PMDN4015_R Channel Knob 1
16 Channel Knob D-Clip (D: 3.5) 1
17 PMDN4016_R Volume Potentiometer 1
18 Crab-Eye Knob Nut 1
19 PMDN4017_R Channel Potentiometer 1
20 Crab-Eye Knob Nut 1
21 PMDN4018_R Channel & Volume Top Seal 1
22 PMDN4019_R Top Escutcheon 16 Channels 1
23 Top Adhesive 1
24 PMDN4023_R Battery Latch 1
25 Battery Latch Shaft 1
26 Battery Latch Tape 1

Motorola Mag One Series Specifications

General

Power Output	VHF: 5W, UHF: 4W
Channels	16
IP Rating	IP54
Programmable Buttons	2
Voice Scrambler	No
CTCSS/DCS Codes	Yes
Scanning	Yes
Vox	Yes
Battery Type	Li-Ion
