Motorola Mag One Series User Manual

2-14
Reference
No
Table 2-1 Parts List
Part No Part Name
Mechanical View and Parts List
Qty
27
PMDD4000_R
†
136 - 150 MHz 5W PC Board (EPP) 1
PMDD4001_R* 150 - 174 MHz 5W PC Board (non-EPP) 1
PMDD4005_R
†
150 - 174 MHz 5W PC Board (EPP) 1
PMDD4006_R* 148 - 174 MHz 5W PC Board (non-EPP) 1
PMDD4007_R
†
148 - 174 MHz 5W PC Board (EPP) 1
PMDE4000_R
†
403 - 425 MHz 5W PC Board (EPP) 1
PMDE4001_R* 450 - 470 MHz 4W PC Board (non-EPP) 1
PMDE4005_R
†
450 - 470 MHz 4W PC Board (EPP) 1
28 PMDN4068_R Radio Chassis (EPP) 1
PMDN4024_R Radio Chassis (non-EPP) 1
29 Thermal Pad 1
30 PTT Insulation Tape 1
31 Insulation Tape 2
32 PMDN4028_R Tuning Hole Sticker (Small) 2
33 PMDN4029_R Tuning Hole Sticker (Big) 2
34 PMDN4047_R Moto Caution Label 1
35 PMDN4030_R Dust Cover 1
36 PMDN4031_R Audio Jack 1
37 Audio Bracket 1
38 PMDN4032_R Audio Jack Seal 1
39 PMDN4033_R Microphone 1
40 Microphone Boot 1
41 PMDN4034_R Antenna Bracket 1
42 PMDN4035_R PTT Tact Switch 1
43 PMDN4056_R Programming Button Tact Switch 2
44 PMDN4036_R Speaker Connector 1
45 PMDN4037_R Pogo Pin Seal 1
46 Pogo Pin Housing 1
47 Pogo Pin 2

Motorola Mag One Series Specifications

General

Power Output	VHF: 5W, UHF: 4W
Channels	16
IP Rating	IP54
Programmable Buttons	2
Voice Scrambler	No
CTCSS/DCS Codes	Yes
Scanning	Yes
Vox	Yes
Battery Type	Li-Ion
