Motorola Mag One Series User Manual

Mechanical View and Parts List
Reference
No
2-15
Table 2-1 Parts List
Part No Part Name Qty
48 PMAD4050_R Mag One™ 136-150MHz Antenna 1
PMAD4051_R Mag One™ 150-174MHz Antenna 1
PMAE4019_R Mag One™ 403-425MHz Antenna 1
PMAE4020_R Mag One™ 450-470MHz Antenna 1
PMAE4028_R Mag One™ 490-512MHz Antenna 1
49 PMLN4743_ Mag One™ Spring Belt Clip 1
50 PMNN4071_R Mag One™ NiMH Battery 1200mAH 1
PMNN4071_RC Mag One™ NiMH Battery (Chinese Label) 1
51 PMDN4058_R PCB-Chassis Tape for PMUD2085A_, 1
PMUD2086A_, PMUD2087A_,
PMUD2171A_, PMUE2384A_,
PMUE2385A_, PMUE2386A_
PCB-Chassis Tape for PMUD2085B_, 2
PMUD2086B_, PMUD2087B_,
PMUD2171B_, PMUD2088A_,
PMUD2221A
PCB-Chassis Tape for PMUE2384B_, 3
PMUE2385B_, PMUE2386B_,
PMUE2387A_, PMUE2736A_
52 PMDN4025_R O-Ring 1
53 PMDN4027_R PCB Screw 10
*boards must be used with PMDN4011_R and PMDN4024_R.
†
boards must be used with PMDN4067_R and PMDN4068_R.

Motorola Mag One Series Specifications

General

Power Output	VHF: 5W, UHF: 4W
Channels	16
IP Rating	IP54
Programmable Buttons	2
Voice Scrambler	No
CTCSS/DCS Codes	Yes
Scanning	Yes
Vox	Yes
Battery Type	Li-Ion
