6/29/98 37
Disassembly
Step 3.
Remove the flip by pulling
up on the hinge pin side and
out on the other side.
The hinge shaft may come
loose from the flip.
Flip Removal
Step 1.
Using the the pointed end
of the plastic dissassembly
tool, pry off the left side of
the cover.
Step 2.
Using the point end of the
plastic prying tool insert it
on the right side of the
locking tab. While pushing
inward, force the locking tab
to the left. Once the tab is
released slide the cover
away from the flip.
