Parameter Value
Weight g <180 with PMNN4411A Li-Ion battery
Battery Operating Life (Time Expected) 05/35/60 > 8 hr
Talkgroups - TMO
4000 Entries (up to 2048 entries in one folder)
2048 Unique entries
Talkgroups - DMO 1024 Entries
Folders - TMO 256
Folders - DMO 128
Favorite Groups - Talkgroups accessible through RCU 10 Favorite Groups with 10 Entries
Operating Temperature °C -30 to +60
Note: Li-Ion battery performance degrades at
-10 °C
Storage Temperature °C -40 to +85
Humidity ETS300 019-1-7 class 7.3E, up to 95% R.H @ 50o C for
8 Hours
Dust and Water IP54 (cat.2)
Salt Fog 8 hr exposure to 5% saline solution at 35 °C
Shock (Mechanical), Drop & Vibration ETS 300 019-1-7 class 5M3
Table 6: RF Specification
Parameter Value
Frequency Bands MHz 380–430 MHz
RF Channel Bandwidth kHz
25
Transmitter RF Output Power W 1
RF Power Control 3 Steps of 5 dB
RF Power Level Accuracy +/-dB 2
Receiver Class A and B
Receiver Static Sensitivity dBm -112 minimum (-116 typical)
Receiver Dynamic Sensitivity dBm -103 minimum (-106 typical)
Table 7: GPS Specification
Parameter Value
Simultaneous Satellites 12
Mode of Operation
Autonomous or Assisted (A-GPS)
Important: The A-GPS feature requires
network support. Contact network operator
for availability of support.
Table continued…
22 | Product Overview
