Motorola TETRA MTH800 - Transmitter Tests; Call Processing Tests

4.1 - 4 MTH800 TETRA Handportable Terminal / Basic Service Manual TEST SETUP & TESTING 380-430MHz
Transmitter Tests
1. Power Burst (Control Range)
2. Power Profiles
3. Tx Burst Timing Error
4. Vector Error RMS and Peak
5. Tx Frequency Error
Call Processing Tests
1. Talk Back
2. Call to Mobile
3. Call
Processing
Talk Back
1KHz Test
Signal
Group Mode
-50dBm
4. Call
Processing
Call to Mobile
Private 4 digit random
number & “Send”
28-32dBm
RF Gen Level
Burst Power
-90dBm 28-32dBm
Timing Error <=0.25 Symbols
Vector Error Max 10% RMS, 30%
Peak
Frequency
Error
-/+ 100Hz
No. Test Name Test Setup Terminal Setup Test
Conditions
Limits
