TEST SETUP & TESTING 440-470MHz MTH800 TETRA Handportable Terminal / Basic Service Manual 4.2 - 5
Duplex Test
Digital Duplex Test (Tx)
Measurement Capabilities:
Bar charts (Tx Power, Freq. Err, Vector Rms.), Spectrum Analyser, Power
Analyser, Vector Analyser, Vector Diagrams
How to Configure the IFR 2968 Setup
Perform the following steps to configure the IFR 2968 with the terminal set:
1. Turn ON the IFR.
2. Press “Systems” Mode Key (wait until the digital system is initialised).
3. Press the “Tetra Mobile” softkey.
4. Press the “Setup” softkey and enter the System Parameters Screen.
5. Press the “Channel Plan” softkey.
6. Press the "More" key.
7. Press "Tetra 450MS" softkey. The "Control Channel" automatically changes
to "2400"; and "Traffic Channel" automatically changes to 2500. Press twice
the “Traffic Channel” softkey and check that the marker goes to Timeslot.
Press Data key “3” followed by the “Traffic Channel” softkey, to change to
Timeslot “3”.
8. Press “Country Code” softkey. Enter “753” and “Country Code” softkey.
9. Press “Network Code” softkey. Thereafter, enter “2361” and press “Network
Code” softkey.
10. Press “Base Color” softkey. Thereafter, enter “1” and press “Base Color”
softkey.
11. Press “Location Area” softkey. Thereafter, enter “23” and press “Location
Area” softkey.
12. Press "More" softkey.
13. Press "Min Rx Level" softkey. Thereafter, enter "-110dBm".
14. Press "Max Tx Level" softkey. Thereafter, enter "30dBm".
15. Press "Access Parameter" softkey. Thereafter, enter "-53dBm".
16. Press "Base Service" softkey.
Note: You are entering base services setup.
