6 - 24 MTH800 TETRA Handportable Terminal / Basic Service Manual MAINTENANCE
MTH800 Unit - Exploded View
MTH800 components are listed in the table below. The first column marked with
a # sign provides you with the call out numbers of the components as marked in
Figure 16, Figure 17, and Figure 18.
MTH800 Components List
# Description Part/Kit
1. Thick battery cover with rubber 0188809V59
2. Slim battery cover with rubber 0188809V58
3. Long Antenna
- 380-430 MHz, or
- 430-470 MHz 1
8586381J11
8566504A01
4. Short Antenna
- 380-430 MHz, or
- 430-470 MHz 1
8586381J10
8566504A02
5. Back housing assembly 0188809V42
6. Rubber cap, blue (2) 4387504V52
7. Rubber cap, yellow 4387504V51
8. Rubber cap, green 4387504V53
9. Logo label 5486278T02
10. Vehicle adapter internal seal 0187506V59
11. Tamper evident label 5466516B03
12. FCC Label 5487503V69
13. Model label 5487503V70
14. Vibrator 5916357H01
15. Washer (6) 0487779V12
16. Screw (6) 0387839V75
17. Battery contact seal 3271289L01
18. Battery lock latch 5587581V07
19. Vehicle adapter external seal 3287842V20
20. Antenna switch external seal 3287842V18
21. Antenna switch internal seal 3287842V05
