MAINTENANCE MTH800 TETRA Handportable Terminal / Basic Service Manual 6 - 31
Note: PCB No. (380-430 MHz) = 8471339L05
PCB No. (440-470 MHz) = 8416289H07
Accessories Replacement Parts List
FBN7009 Packaging 1 per 20
terminals
0487779V12 Washer 6
4387504V52 Rubber cap, blue 2
4387504V51 Rubber cap, yellow 1
4387504V53 Rubber cap, green 1
7586477Z01 Poron pad (glued on chassis) 1
4387504V34 Spacer (glued on display board)
0788394V58 Audio connector support 1
Kit Number MTH800 Model Description
Batteries
SNN5705 Standard battery, 800 mAh, LiIon (without battery door)
NNTN4655 Extended battery, 1500 mAh, LiIon (without extended battery door)
0188809V59 1500 mAh battery door
0188809V58 800 mAh battery door
Chargers
NNTN4250 Travel charger (power supply only)
WALN4092 Rapid travel charger kit including UK and Euro plugs (contains NNTN4250
+SYN7456 +SYN7455)
FTN6306 Dual pocket desktop charger base (requires travel charger WALN4092)
1587845S02 Insert for dual pocket desk top charger
SYN7456 Plug adapter EU for travel charger NNTN4250
SYN7455 Plug adapter UK for travel charger NNTN4250
WPLN4175 Multi-unit Charger 6 pockets with Euro cord
WPLN4176 Multi-unit Charger 6 pockets with UK plug
WPLN4177 Multi-unit Charger 6 pockets with US Plug
RLN5643 Wall mount bracket for multi-unit charger
Vehicular Adapters
FLN9469 Vehicle power adaptor
FTN6307 Hands-free Digital Car Kit (incl. cradle, junction box, remote speaker mic,
PTT)
Part/Kit Number MTH800 Model Description Quantity
