Motorola V360 Service Manual

6809493A69-O May 18, 2005 9
Level 1 and 2 Service Manual Specifications
Specifications
General Function Specification
Frequency Range GSM 850
824-848 MHz Tx
869-893 MHz Rx
Frequency Range GSM 900
880-915 MHz Tx (with EGSM)
925-960 MHZ Rx
Frequency Range DCS 1800
1710-1785 MHz Tx
1805-1880 MHz Rx
Frequency Range PCS 1900
1850-1910 MHz Tx
1930-1990 MHz Rx
Channel Spacing 200 kHz
Channels 174 EGSM, 374 DCS, 374 PCS, 124 GSM 850 carriers with
8 channels per carrier
Modulation GMSK at BT = 0.3
Transmitter Phase Accuracy 5 Degrees RMS, 20 Degrees peak
Duplex Spacing 45 MHz
Frequency Stability ± 0.10 ppm of the downlink frequency (Rx)
Operating Voltage +3.2V dc to +5.5V dc (battery)
+4.8V dc to +6.5V dc (external connector)
Transmit Current Drain 101-260 mA average talk current drain
Stand-by Current drain 5 mA (DRX2), 2 mA (DXR9) typical
Temperature Range -10° C to +55° C (+15° F to +130° F)
Dimensions, with 810 mAh Li Ion
battery
47 mm x 90 mm x 24.3 mm
(1.85 inches x 3.54 inches x 0.95 inches)
Size (Volume) 85 cc (5.18 in
3
), with battery
Weight 110 grams (3.88 oz), with battery
Battery Life, with standard 810 mAh
Li-Ion Battery
Talk Time 150-450 minutes
Standby time 140 -240 hours
All talk and standby times are approximate and depend on
network configuration, signal strength, and features selected.
Standby times are quoted as a range from DRX=2 to DRX=9.
Talk times are quoted as a range from DTX off to DTX on.
Battery Charge Time 4 hours to 90% of 810 mAh capacity
Alert volume Max 95 dB @5cm, 0.5 Watts input
Transmitter Function Specification
RF Power Output 32 dBm nominal GSM 850/900
29 dBm nominal GSM 1800/1900
Output Impedance 50 ohms nominal
Spurious Emissions -36 dBm from 0.1 to 1 GHz, -30 dBm from 1 to 4 GHz
Receiver Function Specification
Receive Sensitivity Better than -103 dBm
RX Bit Error Rate (100k bits) Type II < 2%
Speech Coding Function Specification
Speech Coding Type Regular pulse excitation/linear predictive coding with long term
prediction (RPE LPC with LTP)
Bit Rate 13.0 kbps

Motorola V360 Specifications

General

Bluetooth	Yes
Infrared data port	No
Ringer type	Polyphonic
Rear camera resolution	640 x 480 pixels
Interface	mini-USB & bluetooth
Networking type	GSM
Playback formats	midi, mp3, wav
Operating frequency	900/1800/1900 MHz
Display type	TFT
Display resolution	176 x 220 pixels
Display number of colors	262144 colors
External display resolution	96 x 80 pixels
External display number of colors	Monochrome
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Product color	Blue
Internal memory	5 MB
Data network	GPRS

Weight and Dimensions

Depth	47 mm
Width	90 mm
Height	24 mm
Weight	104 g
