Motorola Confidential Proprietary
V975/V980/C975/C9803G Flash Procedures
1-6
Draft 1.0
Force Flash Procedures
The procedures described in this section apply only to
situations where the 3G terminal will not initiate it’s nor-
mal power up sequence, but may recover functionality
by a repeat flash procedure.
There are two possible alternatives to place the 3G ter-
minal in force flash mode.
Key Hold Solution
Hardware: Refer to Figure 1 (USB solution)
Step 1. Remove the battery from the 3G terminal
Step 2. Prior to connecting the USB cable, press and
hold “#” and “*” keys from the 3G terminal
Step 3. Attach the USB cable
Step 4. Verify that the RSD application detects the 3G
terminal, if it’s not detected, press and hold the
gaming keys once again.
Force Flash USB Cable Solution
Hardware: Refer to Figure 1-1 (USB solution), except,
replace USB cable (SKN6311A) with
force flash cable (SKN6168A)
Step 1. Connect the force flash cable in the same man-
ner described in Figure 1-1.
Step 2. The 3G terminal will automatically be placed in
force flash mode. There’s no need to press the
power key. The RSD application will now de-
tect the 3G terminal
Force Flash Procedures
