Attaching the Universal Connector
Cover (Dust Cover)
The universal connector is located on the antenna
side of the radio. It is used to connect MOTOTRBO
accessories to the radio.
Insert the hooked
end of the cover into
the slots above the
universal connector.
Press downward on
the cover to seat the
lower tab properly
into the RF
connector.
Turn the
thumbscrew
clockwise to secure
the connector cover to the radio.
To remove the universal connector cover, press down
on the cover and turn the thumbscrew
counterclockwise. Lift the cover up, slide the
connector cover loop upwards, and remove it from the
attached antenna.
Replace the dust cover when the universal connector
is not in use.
Universal
Connector
