Mountz HDC-35i - Table of Contents

Index
■ General & Specific safety rules
6
1. Products introduction
9
2. Key features
9
3. Specification
3.1 Driver
10
3.2 Manual screwdriver models
11
3.3 Automation screwdriver models
12
3.4 Controller (HDC) specification
13
4. LAY-OUT
4.1 Screwdriver LAY-OUT
14
4.2 HDC Controller LAY-OUT
15
4.3 HDC Controller Dimensions
16
5. Operation
5.1 Front panel of controller
18
1) FND Display
18
2) Key Buttons
19
5.2 Parameter number group
20
5.3 Preset # & parameters
21
5.4 Torque, speed & angle setting (I) - by PC program
22
5.5 Torque, speed & angle setting (II) - on the front panel
23
5.6 Details of each parameter numbers
24
5.7 Error code
45
5.8 Preset # selecting by sensor
48
5.9 Wiring example of check out signal output
49
5.10 Preset # selecting in 25P I/O port
50
