Operation Section
9
2.3 Internal Structure
ILL00851-00
Outdoor Fan Motor
Indoor Fan
Outdoor Fan
Compressor
Service Box
Connector for Optional
Condensate Pump
Electronic
Expansion Valve
Drain Tank
Indoor Fan Motor
Indoor
Heat Exchanger
Drain Pan
Outdoor
Heat Exchanger
4-Way Valve
Drain Switch
Accumulator
High Pressure
Switch
