UC-8410A HW UM Hardware Connection Description
4-6
DI/DO
The UC-8410A has 4 channels for digital outputs and 4 channels digital inputs. The I/O pinouts are shown in the
following figures:
Digital Input Wiring
Dry Contact
Wet Contact
NOTE
If
you are using wet contacts, you must connect the “COM” pin to power.
Digital Output Wiring
