UT1811 - 1010 - UK01
Page 19/32
ADJUSTABLE MULTISPINDLE HEADS
6 Machine connection
6 MACHINE CONNECTION
6-1 Heads suitable for installation to units and drilling/tapping
machines
• The power transmission works by means of driver and joint, depending on the type of
connection of the machine spindle.
Fig. 3 shows the different connection systems between the machine and the adjustable
multispindle head.
Fig. 3
CONNECTION
COUPLING
FLANGE
JOINT FOR
ISO SPINDLES
DRIVER FOR
SPINDLES DIN 55058
DRIVER
DIN 238
DRIVER
MORSE TAPER
JOINT
DRIVER FOR
SPINDLES
WITH COLLET
ADJUSTABLE
MULTI SPINDLE
HEAD
