UT1811 - 1010 - UK01
Page 7/32
ADJUSTABLE MULTISPINDLE HEADS
1 General notes
1 GENERAL NOTES
1-1 Purpose of the document
The information in this manual has been provided to highlight the operations necessary for
the end user to correctly use and service the MPA heads. Information concerning installation,
adjustment and maintenance relating to the head you have purchased can be found in this
document.
Special attention has been given to questions matters involving the safety and safeguard of
the operators’ security, together with the safeguard and respect of the work area.
Before using the multispindle head, read carefully this manual and, in case of doubts, contact
the MPA After-sales technical service.
1-2 Symbols
In order to direct the readers’ attention on particularly important points in this manual, the
following graphs have been used:
DANGER Indicates an operation that must be carried out scrupulously in that it may
expose the operator to serious injuries.
IMPORTANT Indicates an operation that may cause damages to the adjustable head,
or simply recall the attention of the reader on certain particularly important
operations.
ADJUSTMENT Indicates adjusting operations. The operations marked with this symbol must
be carried out by technically qualified staff and with adequate mechanical
knowledge.
