UT1811 - 1010 - UK01
Page 22/32
ADJUSTABLE MULTISPINDLE HEADS
7 Installation
7-1 Balancing
During applications involving the use of heavier heads models, the return spring of the drill
could not able to support the weight of the head and, therefore, the spindle will tend to lower
itself.
In this case, it is necessary to execute a system to solve this problem.
In case of doubts, the MPA technical department is always at your disposal.
Fig. 5
DANGER In carrying out this operation, do not modify the structure or holes on the head.
MPA declines every liability for any damages to persons or things resulting from the above
operation.
