ADJUSTABLE MULTISPINDLE HEADS
8 Adjustment
At the end of this operation fasten the screw 1 (Fig. 6) of each spindle unit using a torque
wrench to reach the torque shown in Table 1.
Table 1
Head Model Torque (Nm)
Series MINI (ER 8) 6
Series 800 (ER 11 - ER 16) 15
Series 820 (ER 20) 20
Series 100 (ER 25 - DIN 55058)
25
Series 900 (Milling) 25
