MPP Solar PIP8048MAX User Manual

23
37
Reset all stored data for PV
generated power and
output load energy
Not reset(Default)
Reset
41
Maximum battery
discharging current
Disable (Default)
If selected, battery discharge
protection is disabled.
30A
The setting range is from 30 A to
150 A. Increment of each click is
10A.
If discharging current is higher
than setting value, battery will
stop discharging. At this time, if
the utility is available, the
inverter will operate in bypass
mode. If no utility is available,
the inverter will shut down after
5-minute operation in battery
mode.
150A
51
On/Off control for RGB LED
*It’s necessary to enable
this setting to activate RGB
LED lighting function.
Enabled (default)
Disable
52
Brightness of RGB LED
Low
Normal (default)
High
