5 Mounting
3110014218/00 EN
2. Fit the drive shaft into the Cardan joints.
3. Hold the drive shaft in position and drill a hole (Ø2.9mm) in each of the
Cardan joints.
4. Insert a suitable spiral steel pin (Ø3mm) into the drill hole to secure the
Cardan joints.
5. NOTICE! To ensure the correct function of the drive shaft, the inclination
of the drive shaft in relation to its working axis may not exceed 45°. The
recommended maximum drive shaft inclination is 30°.
5.6 Electrical connection
DANGER
Electric shock!
Risk of fatal injury due to electrical voltage when connecting
the device.
► Ensure that all cables are free of voltage during connection work.
5.6.1 Cable recommendation
Please note the following recommendation when wiring the device:
▪ To make the connection, you need suitable ring cable lugs and cable
glands that are not included in the scope of delivery.
▪ The cables used must be flame-resistant in accordance with
IEC60332-1-2 or UL2556VW-1.
Cable Conductor cross-section Connection
Signal lines 1.5...4mm
2
M5 thread
Protective conductor ≥ all other lines M6 screw
Table5: Cable recommendation
5.6.2 Electrically connecting the reed switches
The reed-type switches installed in the device are either normally open con-
tacts or change-over contacts.
1. Unscrew the screws (3x M5, hex-wrench 4mm) on the terminal box and
remove the cover.
