MR CEDASPE DAROC EDS-R Series User Manual

10 Technical data
50 10014218/00 EN
Reed-type switches
Number and type Max.2 normally open contacts or 2 change-over
contacts
Nominal voltage 24…240VDC
Up to 230VAC
Max. current AC/DC NO contact: 2A
CO contact: 1A
Min. switched current Normally open contact: 10mA
Change-over contact: 5mA
Breaking capacity DC Normally open contact: 24...240VDC
250W L/R < 40ms
Change-over contact: 24...240VDC
130W L/R < 40ms
Breaking capacity AC Normally open contact: Up to 230VAC
400VA cosφ > 0.5
Change-over contact: Up to 230VAC
250VA cosφ > 0.5
Insulation resistance 1,000MΩ/500VDC
Terminal box
Cable inlet gland M20x1.5/M25x1.5 (adapter)
Connection terminals M5 thread
Protective conductor connection M6 screw
