MR VACUTAP - Page 91

A1
© MASCHINENFABRIK REINHAUSEN GMBH 2014
DIMENSION
IN mm
EXCEPT AS
NOTED
DOCUMENT NO.
STAND.
CHANGE NO.
DFTR.
CHKD.
SHEET
DATE
MODEL WITH UPPER GEAR UNIT
-
SED 5995440 001 00
1
101168860E
STREMPEL
06.06.2018
1:5
1087254
SCALE
NAME
/
STREMPEL06.06.2018
MATERIAL NUMBER
SERIAL NUMBER
07.06.2018 PRODASTSCHUK
ON-LOAD TAP-CHANGER VACUTAP® VVS®
PRV-FLANGE FOR PRESSURE RELIEF VALVE
1
THE REPRODUCTION, DISTRIBUTION AND UTILIZATION OF THIS DOCUMENT AS WELL AS THE COMMUNICATION OF ITS CONTENTS TO OTHERS WITHOUT EXPRESS AUTHORIZATION IS
PROHIBITED. OFFENDERS WILL BE HELD LIABLE FOR THE PAYMENT OF DAMAGES. ALL RIGHTS RESERVED IN THE EVENT OF THE GRANT OF A PATENT, UTILITY MODEL OR DESIGN.
GASKET
M
- MARK ( DRIVE SIDE )
M
DETAIL Z
16O
M 12
O 235
O 270
O 130
15
MA = 50 Nm
Z
92
148,5
97
136
14
2
7
°
6
0
°
6
0
°
6
x
(
=
3
6
0
°
)
339,5
