MRW Vib-Control 04 User Manual

MRW Vib-Control 04
12 v. 34 27. Oktober 2014
Technical
data
3 Technical data
3.1 General specifications
Dimensions
Specification
Value
Unit
Housing dimension
H x W x D
198x98x81
mm
3.2 Connection ratings
Connected loads, electric
Specification
Value
Unit
Input voltage
110-250
V
Power frequency
50-60
Hz
Power consumption
2,5
A
Max. power consumption for 0.2
sec.
5
A
Output current
8
A
External power supply 24V DC
0,2
A
Fuses (slow blow)
2,5
A
Protection class
IP 54
3.3 Operating conditions
Specification
Value
Unit
Temperature range
15 – 40
°C
Relative humidity, maximum
60
%
3.4 Serial number
6
Fig. No. 1:
The serial number can be found on the right-hand side of the
housing.
Fig. No. 2:
The software version is shown when the device is switched on. The
device must first be switched off until the text in the display no
longer appears – this can take up to 5 minutes
