MRW Vib-Control 04
20 v. 34 27. Oktober 2014
Structure
and function
4.5 Status messages in the display
53 % 52.2 Hz
Alternative
53% 4.3 A Output vibratory drive
53% 1.8 A Input control unit
Standard display in automatic operating mode
Specification of power in %. Vibratory drive work frequency
Alternative setting
Specification of power in %. Power consumption at input or output
Stop buttons!
The vibratory drive was stopped via the “Stop” button
External Stop!
The vibratory drive was stopped via the control input for the PLC or
the MRW RoboPot System.
Backup Stop!
The vibratory drive was stopped via a directly connected backup
sensor or MAX sensor
4.6 Fault messages in the display
Danger!
Fault messages in the display always indicate an
electrical problem. The fault must be remedied by a
qualified electrician.
Short-circuit
This message is displayed when there is a short-circuit at the output
of the control unit to the vibratory drive. Magnetic coils or cables are
defective.
The feed speed is then set to 0%.
After the fault is rectified by an electrician the value must be reset.
“Overload”
This fault occurs when the power consumption of the drive is higher
than the permitted value set in the menu. This function serves to
protect the drive.
Check the air gap and coils of the vibratory drive and/or, if
applicable, increase the permitted power consumption of the drive.
The highest possible value is 8A.
