Internal/Buttons
External 0-10V =
xx V
External
potentiometer=
xx%
Whether the speed is to be controlled via
the control unit or via external inputs is
set here. The status of the external inputs
is displayed.
Internal/Buttons
+24V Stop = xxV
+24V Start = xxV
Whether the vibratory drive is to be
activated by the buttons or via an
external input can be set here.
The input can be inverted.
The applied voltage at the input is
displayed.
+24V Stop = xV
0V Stop = xV
The vibratory drive can be stopped here
via a MAX sensor.
The input can be inverted.
The applied voltage at the input is
indicated in the display.
+24V Start = xV
0V Start = xV
The vibratory drive can be started here
via a MIN sensor.
The input can be inverted.
The applied voltage at the input is
indicated in the display.
The delay for the gentle start can be set
here for between 0.1 and 9.9 seconds.
During this time, power is slowly
increased up to a preset target value.
The delay for the gentle stop can be set
here for between 0.1 and 9.9 seconds.
During this time, power is slowly reduced
to a stop.
How long the signal on the MAX sensor
must be at “high level” before the
vibratory drive is stopped is set here.
Without MIN sensor: How long the signal
on the MAX sensor must be at “low level”
before the vibratory drive is stopped is
set here.
With MIN sensor: how long the signal on
the MAX sensor and on the MIN sensor
must be at “low level” before the vibratory
drive is stopped.
The maximum permissible speed of the
vibratory drive in % is set here.
