Installation
and commissioning
Input MAX sensor PNP
A MAX sensor which controls the filling of a belt section or an
accumulation pipe together with a MIN sensor can be connected
here.
Alternatively, a sensor can be used here solely as an accumulation
stop without a MIN sensor.
A PNP sensor must be used. The function of the switching input
can be inverted. It is therefore irrelevant whether the sensor works
as “normally closed” or “normally open”.
Input MIN sensor PNP
A MIN sensor which controls the filling of a belt section or an
accumulation pipe together with a MAX sensor can be connected
here.
A PNP sensor must be used. The function of the switching input
can be inverted. It is therefore irrelevant whether the sensor works
as “normally closed” or “normally open”.
Option: Input for external
potentiometer
The feed performance of the vibratory drive can be optionally
controlled via an external 10kohm potentiometer.
The lower and upper limits of the performance programmed in the
Vib-Control 04 menu are adhered to.
