MS ENERGY ATOM a1 - 3 LCD Display & Controller

ENG
10
1. Frame 10. DiscBrake 19.Backfender
2. SeatPost 11. DiscBrakePlate 20.Derailleur
3. Saddle 12. Hub 21.Motor
4. Verticalhandle
stems
13. Rim 22.FrontFender
5. Acrosshandle
Stems
14. Tyre 23.RearRack
6. Shifter 15. Speedsensor 24.Battery
7. BrakeLever 16. Crank 25.RearLight
8. FrontFork 17. Pedal 26.Mainstand
9. Headlight 18. Chain 


3LCDDISPLAYCONTROLLER

LCDControllerKM529providesawidearrayoffunctionsandindicatorstofit
theuser’sneeds.Theindicatedcontentsareasfollows:
 BatteryVoltage
 Speed(Real‐timespeed,AveragespeedandMaxspeed)
 TripdistanceandTotaldistance
 PASLevel
 HeadlightStatus
 ErrorCode
 Variousparameterssettings,suchaswheelsize,speed‐limit,backlight
brightnessandsoon.

MonitorArea









ErrorCode
Speedunit
Powerlevel
DistanceUnit
Set
Battery
Distance
Speed
