MS ENERGY ATOM a1 - Installation of Front Wheel

ENG
16
Installationoffrontwheel

1. Takeoutthefrontwheel,and
loosen the nut and hook on the
frontwheelaxis;
2. Removetheblackplasticrack
belowtheFrontfork,andplacethe
frontwheelaxisintotheFrontfork
contactpin;
3. Turn the hook and nut (* front
fender stick) to the front wheel
axis, and tighten the nut with
15mm opening wrench by 18N.m
torqueandinstalltheprotectivecap
onthenut.
When fastening the front wheel nut
axis,pressdowntheFrontforkbyforce
sothatthefront wheel axiscanwork
closelywiththeFrontfork.
Note: some models of front fender
sticksneedtobeinstalledonthefront
wheelaxis.

InstallationofquickreleasefrontwheelandVbrake*

1. Takeoutthefrontwheel,androtate
the quick release handle for laps
counterclockwise.
2. Removetheblackplasticrackbelow
theFrontfork,andtaketheVbrake
conduitoutoftheVbrake,andput
the front wheel axis into the Front
forkfootcontactpin.

3. Rotatethequickreleasehandlefor
laps clockwise and lock the quick
release handle to ensure the front
wheelcannotbeloose;
4. ExtrudetheVbrakebyforce,andput
theVbrakeconduitintotheVbrake.
