MS ENERGY ATOM a1 - Installation of Steering Handle

ENG
18
①Discbrakeplate
②Discbrake
③InnerhexangularM6×16mmbolt
④Brakeblock
⑤FixedhangeroftheDiscbrake

Note:whenfixingtheDiscbrakebolt,dragthelowerpartoftheDiscbrakewith
hand,andpushtheDiscbrakeupwardasfaraspossible.

*Option,dependsaboutbraketypeonyourmodel

Installationofsteeringhandle(TrakingBike)

1. TakeouttheAcrosshandleStems,removetheprotectivepaperabovethe
AcrosshandleStems,andspinofffourfixedscrewsontheVerticalhandle
stems
2. RemovethetopcoveroftheVerticalhandlestems,fixtheAcrosshandle
Stems to the Vertical handle stems, and adjust the angle of theAcross
handleStems;
3. Tightenthetopcoverof
the Vertical handle stems
withtheboltby6N.m
torquetoensurethatthe
up and down gap of the
topcoverofthestandpipe
iseven.

① AcrosshandleStems
② TopcoverofVertical
handlestems
③ Topcoverboltof
Verticalhandle
④ 4mmhexagonspanner

Installationofsteeringhandle(CityBike)

1. Takeoutthesteeringhandleassembly,andremovetheprotective
paperabovetheVerticalhandlestems;
2. InserttheVerticalhandlestemsinsidetheFrontforkstandpipe,and
adjustthedirectionandinsertiondepth;
1
2
3
4
