3. Tighten the bolt
inside the Vertical
handle stems with
18N.m torque by
hand.

① Vertical handle
stems
② Safetyline
③ 6mm hexagon
wrench




Installation of R/L pedals
Toattachethepedals,you
willneeda#15wrenchor
spanner.
The two pedals will be
labeled with R (Right
pedal)andL(Leftpedal).
Lineupthe#15wrenchor
spanner, as seen on the
picture,thentwistthepedalstowardthefrontofthebikeuntiltheyare
securelyattached.

Assemblyrequirements
Inordertoensurethecyclingsafetyandusingperformance,the fastening
requirementsforthestandardpartsatthekeyplacesareasfollows:
1. Thetighteningtorqueofthefrontwheelnutisnotlessthan18N.m
2. Thetighteningtorqueoftherearmotornutis35to45N.m
3. Thetighteningtorqueofthemiddleaxiscomponentlockisnotlessthan50N.m
4. ThetighteningtorqueofthecorescrewrodintheVerticalhandlestemsis15to18N.m
5. ThetighteningtorqueoftheAcrosshandleStemsandtheVerticalhandlestemsis15to
18N.m
6. Thetighteningtorqueofthesaddlepiperingis6to8N.m
7. ThetighteningtorqueofthesaddleandtheSeatpostringis15to18N.m
8. ThetighteningtorqueoftheBrakehandleisnotlessthan10to12N.m
9. ThetighteningtorqueoftheDerailleuris8to10N.m

1
2
3
Note:theinsertiondepthofthestandpipecan
notbetooshallow,nottoexposethesafety
