4ASSEMBLYMETHODANDREQUIREMENTS

InstallationofHeadlight
Close the whole power
supply,avoidthepositiveand
negative pole of the lamp
wirefromshort‐circuit,install
theheadlight,anddonotpull
the head light, in order to
avoid the lamp wire from
shedding, causing
unnecessarytrouble.
1. Take out the Headlight
andthefrontfender;
2. Align the hanger of the
frontfenderwiththehole
oftheHeadlightrack
3. FixthehexagonalM6×16
boltinsidethescrewhole
oftheFrontforkwith
10mm opening wrench,
andtightenthebolt.



FrontfenderInstallation

1. Take out the front fender and fix the
fenderhangerandHeadlightrackonthe
FrontforkwithhexangularM6×16bolts
2. FixthepanheadM5×14screwandthe
frontfenderstickonthecorresponding
positionsatbothsidesoftheFrontfork
3. Withthecrossscrewdriver,andtighten
thebolts,asshown.
Whentheliftingearofthefrontfenderis
installed, please fender up as much as
possible so as not to interfere the fender
withthetire.

