ENG 
13
ErrorCodeInfo
Ifthereisaproblemwiththeelectronicsystem,an
errorcodewillappearautomatically.Whenanerror
appears,pleasecheckthecorrespondingpartofe‐
bikeorsendthedisplaytoberepaired.
ErrorCode Definition Solution
21 CurrentAbnormality Checkthemotorphases.
22 ThrottleAbnormality Inspectifthrottlerecoveroriginalstate
23 MotorAbnormality
Inspectifthemotorcableiswellconnected.Inspectif
cablesarewellconnected
24
MotorHallSignal
Abnormality
Non‐HallController:Inspectifmotorphasesarewell‐
connected;
HallController:Inspectifmotorhalliswell‐connected.
25 BrakeAbnormality
Checktheoriginalbrakestatewhenthesystemisfirst
poweredup
30
Communication
Abnormality
Checkthatallcablesarewllconnectedtoeachother.

GeneralSetting
Whenthedisplayispoweredon,holdboth and for2secondstoenter
thesettingsmenuandhold for2secondstoquitthesettingsmenu.

WheelDiameterSetting
While in the settings menu press or to
selectthecorrectvaluetomatchthewheel
diameter. Selectable values include: 16 inch,18
inch,20inch,22inch,24inch,26inch,700C,28
inch.Thedefaultdiameteris26inch.
Press toconfirmthevalueofwheeldiameterandenternextsettingat
thesametime.
Speed‐limitSetting
Whentherider’sreal‐timespeedexceedsthe
speed‐limit setting the controller will cut off
power to the motor. The default speed‐limit
settingis25km/h.Thevaluesofspeed‐limitrange
from12km/hto40km/h.Press or toselect
thedesiredvalueandthenpress toconfirmandenterthenextsetting.
