Control Unit Models 9010 LCD and 9020 LCD

Appendix

MSA

Conditions for

use:

Assembly: Wall-mounted/or Flange

Protection: IP 66/IP 67 EN 60529

Explosion protection: Ex II 2G EEx de IIC T6

[EEx e for cable connection]

Approval: Nemko 01ATEX282

Temperature: -20 °C to +55 °C

Humidity: 5 – 95% rel. humidity; non-condensing

Pressure: 800 – 1,100 hPa

Weight: approx. 2.9 kg

Dimensions: Dia. approx. 100 mm, length approx.

250 mm

Housing material: Stainless steel [ASMT 316/DIN 1.4401]

Further details in the Operating and Maintenance Instructions.

[Part.No. D0770041] Measuring component list: 0770-405/Other meas-

uring components on request
