DESCRIPTION MSA
8 ALTAIR Operating Manual
The response levels for the individual gases are set at the factory and cannot be
changed during operation. After commissioning the instrument, changes are
possible only with the MSA FiveStar
®
Link
TM
software (available as option;
 Description of software).
After commissioning the instrument, the remaining operation time is displayed in
months.
If the ambient air contains higher gas concentrations, the instrument
ignores the Fresh Air Setup and goes directly to measuring mode after
the self-test.
2.2. On-screen Indicators
Fig. 2 Display
1 Self-test in progress
2 Bump check indicator
3 Alarm duration (hour glass)
4 Ready indicator
5 Alarm indicator
6 Battery warning indicator
7 Remaining operation time unit
8 Numeric indicator
9 Gas concentration units
1
6
7
3
4
5
8
9
2
