11
Description
GB
2 Description
2.1 Overview
Fig. 1 Device Overview
The ALTAIR Pump Probe is a hand held portable gas sampling pump integrated
with rechargeable Li-ion battery and has audible and visual alarms, which indi-
cate blocked flow, low battery power and charge status. Pump inlet connects
with a 0,3 m [1 ft] wand or sample line while the pump outlet connects with other
portable gas detection equipment through a 1 m [3 ft] coiled tube. The rubber
over-mold of the main body is constructed of static dissipative plastic. The clear
top portion of the case is designed to observe the filter status.
1 Wand/Sample inlet 5 Horn
2 Battery LED 6 Charge LED
3 Flow LED 7 Coupling Hose
4 POWER ON/OFF button 8 Charge port
