19
Maintenance
GB
4.4 Replacing the Filters
External Filter
The ALTAIR Pump Probe contains a filter to:
- block dust and dirt
- block the passage of water
If the probe tip is accidentally submerged in water, the filter prevents the water
from reaching the internal pump. The filter is not designed to stop other liquids,
such as gasoline or alcohols.
To Replace the Probe Filter
Fig. 3 Replacing Probe Filter
(1) Rotate the cap counterclockwise and pull.
(2) Remove the filter (P/N:10151021) and replace.
(3) Check the pump operation after filter replacement (see chapter 3.1).
Attention!
When replacing external dust and water filters, prevent any dust or dirt around
the filter housing from entering the pump housing. Dust or dirt in the pump unit
may impede pump operation.
