21
Technical Specification/Certification
GB
5 Technical Specification/Certification
5.1 Technical Specifications
Weight 260 g (9.2 Oz)
Dimensions 185 mm x 48 mm x 33 mm
(7.3 inch x 1.9 inch x 1.3 inch)
Alarm Flow LED, Battery Low LED, Charge Indicator LED,
Audible alarm
Audible Alarm >90 dB typical
Flow Rate 250 mL/min (Typical)
Sample Line 3m (10ft), 8m (25ft), 15m (50ft)
long sample line (optional)
Sample Delay Time 1 sec per 0.3 m (1 ft)
Battery Type Rechargeable Li-ion battery
Operation Time 30+ hours @ 25 °C
Charge Time < 4 hours
Temperature Range -20 °C ~ 50 °C, Normal: Operation range
10 °C ~ 35 °C, Charging
-5 °C ~ 40 °C, Storage
Humidity Range 15% ~ 90% relative humidity, non-condensing
Atmospheric Pressure 86 kPa ~ 106 kPa (mm)
Ingress Protection IP65
