MSA FieldServer ProtoNode FPC-N34 - Specifications

11.7 Specifications
ProtoNode FPC-N34/N38/N40/N42 ProtoNode FPC-N35/N39/N41/N43
Electrical
Connections
One 6-pin Phoenix connector with:
Port (+ / - / gnd) - see Interface Table below
Power port (+ / - / Frame-gnd)
One 3-pin Phoenix connector with:
RS-485 port (+ / - / gnd)
One Ethernet 10/100 BaseT port
One 6-pin Phoenix connector with:
Port (+ / - / gnd) - see Interface Table below
Power port (+ / - / Frame-gnd)
One Ethernet 10/100 BaseT port
One FTT-10 LonWorks port
Approvals
FCC Part 15 certified, UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC 62368-1, EN IEC 62368-1,DNP
3.0 and Modbus conformance tested, BTL marked, WEEE compliant, REACH compliant, RoHS
compliant, CSA 205 approved, UKCA and CE compliant, ODVA conformant
LonMark Certified
CAN ICES-003
(A)/ NMB-003(A)
FPC-N42
CAN ICES-003
(B)/ NMB-003(B)
FPC-N34, FPC-N35, FPC-N38, FPC-N39, FPC-N40, FPC-N41, FPC-N43
Power
Requirements
9-30VDC or 12-24VAC - see Section 5 Power up the ProtoNode for power draw per model
Physical
Dimensions
11.5 cm L x 8.3 cm W x 4.1 cm H (4.5 x 3.2 x 1.6 in.)
Weight 0.2 kg (0.4 lbs)
Operating
Temperature
-20 to 70°C (-4 to 158°F)
Surge
Suppression
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Humidity 5-90% RH (non-condensing)
NOTE:Specifications subject to change without notice.
Warning: This equipment is compliant with Class A of CISPR 32. In a residential environment, this equipment
may cause radio interference.
Interface Connections
RS-232
1
RS-485
2
Ethernet
3
LonWorks
4
KNX
2
M-Bus
2
ProtoNode
FPC-N34 2 1
FPC-N35 1 1 1
FPC-N38 1 1 1
FPC-N39 1 1 1
FPC-N40 1 1 1
FPC-N41 1
1
1
FPC-N42 1 1 1
FPC-N43 1 1 1
1. Tx/Rx/GND 2. +/-/Frame Ground 3. 10/100 BaseT 4. FTT 10
ProtoNode Start-up Guide 44
