MSA G1 - Lung Governed Demand Valve; Pressure Reducer; Cylinder and Valve Assembly; Carrier Assembly

20
Maintenance and Care
G1
US
2.15 Removing the E-Module
2.16 Installing the E-Module
(1) Remove the regulator. (See Removing the Regulator Hose for instructions.)
(2) Remove the valve assembly. (See Removing the Valve Assembly for instructions.)
(3) Remove the regulator buttons. (See Removing the Regulator Buttons for instructions.)
(4) Rotate the E-module away from the electrical connector
slot and remove from the Regulator Housing.
(1) Insert the e-module into the regulator housing.
NOTE: Ensure the electrical connector aligns with the
connector slot.
(2) Install the regulator buttons. (See Installing the Regu-
lator Buttons for instructions.)
(3) Install the valve assembly. (See Installing the Valve
Assembly for instructions.)
(4) Install the regulator. (See Installing the Regulator Hose
for instructions.)
